Non-contact JET dispenser
Tin tapping state is very stable during whole high speed strong pressure JET type tin tapping 60000 points process.
Test condition:
- Tin discharge time: 25msec
- Nozzle inner diameter: 400μm

PF142-LT7TO(Particle size:20~38μm)
- Composition of alloy:Sn-1.0Ag-57Bi (liquidus line temperature 138°C)
- Flux model:LT7(halogen-free type)
- Good wettability even in air atmosphere
- No occurrence of solder balls

Conductive adhesive supporting low-temperature mounting: ECA series
• One-component conductive adhesive
• Can be cured at 100°C or less
• Can be used for dispense and printing like solder paste.
